- 5L HJLab Lab Scale Rotary Evaporator - Specifications
| Shanghai HJLab Model: |
5L Rotary Evaporator RE-5000 |
| Temperature Range | RT～180°C (Water/Oil Bath) |
| Rotation Speed/Temperature | LCD display |
| Heating Power | 2,000 W |
| Vacuum | PTFE + Viton Gaskets ( Vacuum Level: < 3 torrs ) |
| Rotation Power | 40 W Specialized Motor, quiet and vibration-free and long-time continuous running |
| Rotation Speed | Rotary Knob stepless control: 20～180 RPM |
| Condenser | Dual-Layer Cooling Coils Condenser Sizing: 100mm Diameter * 590mm Height |
| Rotary Flask | 5L |
| Receiving Flask | 2L |
| Water Bath | Teflon-coated Heating Bath Sizing: 280mm Diameter * 170mm Height |
| Water Bath Lifting | Motorized Water Bath Lifting, Linear Actuator for lifting smoothly |
| Lifting Distance | 0 ~ 120 mm |
| Vacuum Sealing | PTFE + Viton Bi-Directional Composite Sealing | Corrosion-Resistance |
| Valves | PTFE Needle Valves for easy operations |
| Safety | Over-current, Over-temperature, Dry-run, Built-in circuit breakers |
| Best Using Environment | Temperature: 5 ~ 35 °C , Humidity: <= 65% |
| Power Supply | 220V, 50 ~ 60Hz, Single Phase |
| Dimension (W*D*H) | 70*41*88 cm |
| Weight | 43 KG |
